Innovation point

● High Grade

By dividing the main shaft and the balance part of the locking shaft, the weight increase is restrained and the vibration is reduced, so as to realize the balanced beating up of the loom at high speed.

● Variety applicability

Independent research and development of industrial textile weaving technology for high-performance fiber materials can realize the weaving of special specification fabrics from general fabrics to home textile, high-end fabrics (double-layer fabrics), special industrial fabrics, etc.

● Water Saving

By redesigning the weft insertion system and the shedding device, a single loom can save 10% water.

● Energy Saving

The direct-drive motor and the newly optimized control system reduce the power consumption of the whole machine by more than 20%.

● More Stable and More Efficient

Adopting integrated wall board and optimizing the frame structure, beating-up mechanism and shedding device, the loom's high speed and stability are obviously improved compared with the original machine.

● Better Weft Insertion

The optimized design of the weft insertion system improves the efficiency of weft insertion and is suitable for high speed weft insertion

● Long Service Life

Adopting U-shaped beating-up shaft with Multi reinforced support seat, the centralized lubrication system and special beating-up balance system to improve the beating-up strength and to make it more wear-resistant, besides, to extend the service life of loom.

●More Efficient Production

 Lower the center of gravity of the loom,improving the design structure of position line and eccentric rocking shaft makes the loom operating greatly improved. Design top speed can reach 1200 RPM;
